Hygienic Air Handling Unit (HAHU)

Trosten is specialist in manufacturing Hygiene Air Handling Units complying to VDI 6022 Part 1:2018 & DIN 1946 Part 4:2018 standards tested at TUV lab in Germany. Various configurations can be offered with different type of heat recovery options like Recuperator, Heat Pipe heat recovery & Run around coils. Components like UV lamp, Hepa filter, EC fans, plug fans can be provided. We are one of the best Hygiene unit manufacturer in the entire GCC and hence could supply our equipment to many reputed hospitals in the region.

Important Features

  • Capacity range: 600 CFM to 60000 CFM
  • Hygienic Air Handling Units tested and certified for VDI 6022 Part 1:2018 & DIN 1946 Part 4:2018 standards by TUV-NORD, Germany.
  • Casing made of aluminium or stainless steel sheet and snap fix (screw-less) panel construction.
  • All hardwares and fasteners shall be of stainless steel material.
  • Drainpan shall be of stainless steel – SS 316 construction.
  • Direct driven plug / EC fans.
  • Heat recovery options with plate type heat exchanger, heat pipe heat recovery, run around coils etc.
  • The gaskets and plastic parts used should be of microbial inertness complying to ISO846.
  • Major components like fan, motor, coil etc. shall be withdrawable type.
  • UV lamp, Hepa filter etc. options available.
Hygienic Air Handling Unit
